Brand Name : BAKTH
Model Number : BAKTH-26650-PACK
Certification : CE, UN38.3, MSDS, and RoHS for cells
Place of Origin : China
MOQ : 2-99PCS
Price : USD120.00-USD125.00/PC
Payment Terms : T/T
Supply Ability : 5000 Units / Month
Delivery Time : 25-35 Days
Packaging Details : Standard Export Carton + Foam Protection
Battery Type : Lithium Iron Phosphate (LiFePO4)
Cell Type : 26650 Cylindrical LiFePO4 Cell
Cell Configuration : 8S3P
Nominal Voltage : 25.6V
Nominal Capacity : 12Ah
Energy : 307.2Wh
Cycle Life : ≥2000 Cycles
BMS Protection : Overcharge, Over-discharge, Short Circuit, Overcurrent Protection
Connector Type : XT60 / Anderson / Customizable
Dimension : About 230mm × 110mm × 75mm (Customizable)
Weight : Approx. 3.5kg
Application : Solar Energy Storage, RV, Electric Scooter, UPS Backup
Product Overview
The 26650 25.6V 12Ah LiFePO4 Battery Pack is a high-capacity and long-lasting battery solution, designed for applications in EVs, solar energy storage systems, and UPS. It uses LiFePO4 cells, known for its superior safety, stable chemistry, and long cycle life.
Specification
Battery Type | Lithium Iron Phosphate (LiFePO4) Battery | Weight | Approx. 3.5kg |
Battery Configuration | 8S3P | Charging mode | CC/CV |
Nominal Voltage | 25.6V | Cycle Life | ≥ 2000 cycles |
Rated Capacity | 12Ah | Charging Temperature | 0 ~ 45℃ |
Max Charge Current | 1C | Discharging Temperature | -20 ~ 60℃ |
Max Discharge Current | 3C | Storage Temperature | -20 ~ 45℃ |
Charge Cut-off Voltage | 28.8V | Humidity Range | 0~85% (non-condensing) |
Discharge Cut-off Voltage | 16V | Certifications | CE, UN38.3, MSDS, RoHS |
Protection Circuit | BMS (Overcharge, Over-discharge, Short-circuit protection) | Warranty | 12 Months |
Key Features
High Safety & Stability: Lithium Iron Phosphate technology ensures high temperature stability, resistance to high pressure, and protection against overcharge, over-discharge, and short circuits, making it safe in harsh environments.
Long Cycle Life: This battery pack offers over 2000 charge-discharge cycles, providing a long-term and reliable power solution for various applications.
Environmentally Friendly & High Efficiency: LiFePO4 batteries are eco-friendly, with low environmental impact and no harmful substances, making them ideal for environmentally conscious users.
Why Choose Us
Profession:We have 23 year battery pack assembly Design and prodution experience.
